Inclined Conveyor Belt Metal Detector for Food Small Bag Metal Detection
The conveyor belt metal detector for food is a new generation of intelligent metal detection equipment developed using digital intelligent technology. It realizes the full digitization and intelligence of metal detection technology, has good performance, is easy to operate, and greatly improves the production efficiency of enterprises. Small bag digital metal detector adopts a pneumatic push rod rejection design and can be installed in the middle of the production conveyor line to connect with the front and rear production conveyor lines, or it can be installed at the end of the production line to connect with the production conveyor line, which can realize fully automated online metal detection and automatic rejection of defective products. Our products have a wide range of specifications, sizes, and styles, providing various customized solutions. Welcome to contact us.
Conveyor belt metal detector for food photos
Inclined Conveyor Belt Metal Detector for Food Small Bag Metal Detection
Detection window height: 120㎜. (Regular size: 100/120/150/200mm, other heights can be customized as required, the higher the window height, the lower the sensitivity.)
Detection window width: 300-500㎜.
Body material: Made of all stainless steel.
Sensitivity: Iron ball φ0.8㎜-φ2.5㎜
Stainless steel 304 type copper, aluminum and other non-ferromagnetic metals ≥φ1.2㎜.
Power supply: 220V 50Hz.
Alarm mode: Sound and light alarm, and automatic shutdown.
External dimensions (length × width × height mm): 1600×840×1005.
Weight: about 250kg
1. Function: Set various functions and modes required, and set the self-check function.
2. Sensitivity: divided into grades, adjustable increase or decrease (1-10 grades adjustable)
3. The frequency shows the degree of interference from the external magnetic field.
4. The sensitivity of the frequency display is adjustable, reflecting the metal index.
5. When trace metal is detected, the sound, light, and instrument alarm at the same time, and the unqualified products automatically return to the shutdown state.
6. It has a self-check function, which can check whether the instrument is normal by itself to avoid unnecessary maintenance.
7. The whole machine is made of industrial stainless steel, which is waterproof and rust-proof, hygienic and easy to clean.
8. The conveyor belt is imported from the Netherlands and is environmentally friendly. Food-grade imported conveyor belts are suitable for temperature ranges from -20C to 65C, and are convenient for operation in the cold storage area.
9. The probe (gantry) can be raised and lowered within the range.
10. The micro-sound system is combined with an environmentally friendly motor, and it will not fail after continuous use.
11. Conveyor belt metal detector for food has a leakage function.
12. Food metal detector has an automatic counting function, the number of finished products, and the number of defective products.
Conveyor belt metal detector for food manufacturers offer a wide range of customization options to tailor the design, functionality and specifications of a checkweigher system to meet the specific needs and requirements of OEM/ODM customers.
Customization options may include conveyor configuration, reject mechanisms, weighing capabilities, software functionality, user interface and integration capabilities.
Conveyor belt metal detector for food is widely use in a full range of applications such as food, pharmaceuticals, textiles, toys, chemicals, cosmetics, raw materials, etc. Different machine types (conveyor type, free fall type, pipeline type, pharmaceutical type, etc.) can meet complete detection requirements.
Inclined Conveyor Belt Metal Detector for Food Small Bag Metal Detection
1.Before packaged, the machines will be test strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrap with plastic sheet and carefully packed in wooden cases.
Q1: What is machine warranty?
Machine warranty for one year. During the warranty period, any non -vulnerable part of the machine is damage. We will replace it for you for free. After the warranty date is issue by the machine, we receive the bill of lading.
Q2: I have never used this digital metal detector machine. How can I control it?
1. Each machine has related operation descriptions.
2. Our engineers can operate through video demonstrations.
3. We can send engineers to on -site teaching. Or welcome you FAT before installation.
Q3: Will you show us the following details when inquiry?
We can.
- Product size (description/photo/sample can be)
- accuracy
- Speed
- Other requirements
